Amplitude Modulated Line-Based Halftoning

A. Ahmed, O. Deussen
Teaser of Amplitude Modulated Line-Based Halftoning

AM line-based halftonings, using (a) a carrier amplitude equal to the peak signal amplitude (some rows overlap), and (b) a zero-energy (suppressed) carrier.


Paper (.pdf, 819.8 KB)


We present a new approach for line-based halftoning of images, where banks of waveforms are modulated by the gray levels of the rendered image. We present examples that employ sinusoidal and triangular waveforms, and highlight some applications,including stylized rendering, halftoning in line-based devices, and education.


  author     = {A. Ahmed and O. Deussen},
  booktitle  = {Computer Graphics and Visual Computing (CGVC)},
  doi        = {10.2312/cgvc.20161294},
  editor     = {Cagatay Turkay and Tao Ruan Wan},
  file       = {:img/Ahmed2016AmplitudeModulatedLine.png:PNG image},
  isbn       = {978-3-03868-022-2},
  issn       = {-},
  publisher  = {The Eurographics Association},
  title      = {Amplitude Modulated Line-Based Halftoning},
  year       = {2016},
  url        = {},
